RF-Series

Designed especially for multi-tier cultivation, the RF-series is a mid-to-high power, dimmable LED luminaire with a high IP rating.

Low Profile LED Grow Light with Valoya's Build Quality

Designed for indoor and multi-tier high PPFD needs.

Valoya RF3 - 02-1
Valoya RF6 - 3
Racking Fixture-3
Racking Fixture-4

rf-series-info
iprating

Up to IP65 with dust & humidity resistant (wet location rated)

lightsettings

Dimmable

heat

Heat directed upwards away from the plants

easyinstall

Easy to install

Powerful, Robust, and Durable

Designed especially for multi-tier cultivation, the RF-series is a mid-to-high power, dimmable LED luminaire with a high IP rating. The robust all-aluminum build, passive cooling, and tempered glass cover ensure a long lifetime in the most demanding environments.

This 300-700W racking fixture can be placed anywhere from 6 to 18in. above the canopy for optimal light distribution and intensity. Typical lifetime is 50,000 hours for the light output to drop to 90% of nominal.

Model Power Input
RF350-3 342 W | 358 W 120 - 277 VAC
RF300-3 322 W | 325 W 120 - 277 VAC
RF300-6 335 W 120 - 277 VAC
RF400-6 440 W 120 - 277 VAC
RF600-6 651 W | 656 W 220 - 480 VAC
RF700-6 686 W | 714 W 220 - 480 VAC

Model

Dimensions

Weight

RF350-3

46.8 x 22.2 x 3.3in

5.8kg / 13.1lb

RF300-3

46.8 x 22.2 x 3.3in

5.8kg / 13.1lb

RF300-6

46.8 x 44.4 x 3.3in

5.8kg / 13.1lb

RF400-6

46.8 x 44.4 x 3.3in

5.8kg / 13.1lb

RF600-6

46.8 x 44.4 x 3.3in

11.6kg / 25.6lb

RF700-6

46.8 x 44.8 x 3.3in

11.6kg / 25.6lb

All models:

0-10V, PWM, Dim to Off

Solray385 | SolrayX
Efficacy (ePAR 280-800nm)

RF300-3
2.65 µmol/J | 2.68 µmol/J

RF350-3
2.65 µmol/J | 2.63 µmol/J

RF300-6
2.75 µmol/J | 2.63 µmol/J

RF400-6
2.64 µmol/J

RF600-6
2.65 µmol/J | 2.7 µmol/J

RF700-6
2.64 µmol/J | 2.7 µmol/J

DLC Certified
CE Marked
RoHS Compliant
Tested and certified to UL & CSA standards

Product Catalog
Get a Quote

RF-Series - Low Profile Racking Fixture for Indoor Grows and Low Ceiling Rooms

The RF-Series is a mid-to-high power LED workhorse. This racking fixture features a minimal 2’x4’ footprint up to 4’x4’ sizing to accommodate a variety of wattage from 325W up to 720W. The low-profile design of the RF-Series racking fixture proves a slim and sleek look for indoor growing and multi-tier racks. This LED grow light is designed with functionality and longevity in mind. The frame of our RF-Series is constructed from durable metal with a tempered glass lense for protection, easy cleaning, and effective light and heat distribution. Best utilized for plant growth from vegetative to flowering, the RF-Series is a low-profile luminaire designed for multi-tier grows or lower rooms. Designed for high PPFD needs, the RF-Series ensure efficient lighting and strong results backed by years of crop science and research.

RF-Series RF700 Racking Fixture Breakdown
